Genie® AWP™ Super Series
• Choose from three bases (standard, narrow, rough terrain) • Choose platform and power options • Super-Straddle option to work over fixed seating • Quick set-up and simple to operate • A tilt-back frame allows AWP-36 and AWP-40 models to roll through doorways • Durable patented Genie® mast system • User-friendly controls • Small outrigger footprint for positioning close to walls • Easy to manoeuvre around corners and over thresholds or debris
S A Platforms © Copyright 2015 Designed by Ashworthweb
S A Platforms © Copyright 2015 (u.12.12.2021) Designed by Ashworthweb
Lifting you HIGHER and SAFER
Genie® AWP™ Super Series
• Choose from three bases (standard, narrow, rough terrain) • Choose platform and power options • Super-Straddle option to work over fixed seating • Quick set-up and simple to operate • A tilt-back frame allows AWP-36 and AWP-40 models to roll through doorways • Durable patented Genie® mast system • User-friendly controls • Small outrigger footprint for positioning close to walls • Easy to manoeuvre around corners and over thresholds or debris
AWP™-20S
Working Height: 8.12 m (26 ft 1 in)
Lift capacity: 159 kg/350 lbs
Power Source:
12V DC/110/50-60 Hz or 220/50-60 Hz AC
AWP™-25S
Working Height: 9.57 m (30 ft 10 in)
Lift capacity: 159 kg/350 lbs
Power Source:
12V DC/110/50-60 Hz or 220/50-60 Hz AC
AWP™-30S
Working Height: 11 m (35 ft 6 in)
Lift capacity: 159 kg/350 lbs
Power Source:
12V DC/110/50-60 Hz or 220/50-60 Hz AC
AWP™-36S
Working Height: 13.10 m (42 ft 5 in)
Lift capacity: 159 kg/350 lbs
Power Source:
12V DC/110/50-60 Hz or 220/50-60 Hz AC
AWP™-40S
Working Height: 14.29 m (46 ft 4 in)
Lift capacity: 136 kg/300 lbs
Power Source:
12V DC/110/50-60 Hz or 220/50-60 Hz AC
*The metric equivalent of working height adds 2 m to
platform height. Imperial measurements add 6 ft to
platform height.
